Window Chain Winder Non-Locking Awning - White Easy Operation

Window Chain Winder | Non-Keyed | Casement & Awning | Multiple Colours

inc GST

Non-keyed window chain winder for casement and awning and casement windows, suitable for aluminium and timber window frames. Features zinc die-cast construction, zinc-coated steel chain, Foldable collapsible handle, and adjustable child-safety limiting. Available in multiple colours.

Weight

.7 kg

Dimensions

28 × 4.9 × 5 cm

This Non-Keyed Window Chain Winder is designed for casement and awning and casement windows in aluminium and timber window frames, providing smooth, reliable operation with a clean, low-profile design. Ideal for residential applications where key locking is not required, while still maintaining built-in safety control.

Manufactured with a die-cast zinc body and internal mechanism and a zinc-coated steel chain, this window chain winder offers long-term durability with a no-corrosion base. The foldable handle ensures compatibility with blinds and curtains, making it suitable for modern interiors and retrofit replacements.

A child-proof limiting system is integrated, with adjustable chain settings at 100 mm, 150 mm, and 300 mm, supporting pool safety and child-safety compliance when installed correctly — without the use of a key.

Available in multiple colour finishes to match common Australian window frames and offered in a range of pack sizes for retail and trade use.

Key Features

Application & Compatibility
• Suitable for aluminium and timber window frames
• Designed for casement and awning and casement windows
• Compatible with common residential window configurations

Operation
• Smooth, controlled winding action
• Through-flyscreen operation
• Foldable handle for use with curtains and blinds

Construction & Durability
• Die-cast zinc body and internal mechanism
• Zinc-coated steel chain
• No corrosion base

Safety & Compliance
• Non-keyed operation
• Built-in child-proof limiting function
• Adjustable opening limits: 100 mm / 150 mm / 300 mm
• Supports pool safety , strata and highrise compliance when installed correctly

Installation
• Fixing screws included
• Suitable for new installations and retrofit applications

Specifications

• Operation: Non-Keyed
• Handing: Left Hand
• Material: Die-cast zinc
• Chain: Zinc-coated steel
• Maximum Opening: 300 mm
• Overall Length: 280 mm
• Fixing Centres: 265 mm
• Depth: 46 mm
• Height: 47 mm
• Rear Length: 273 mm
