Sliding Security Barrier Door Lock | Black | Cylinder + 3 Keys

The Tradebase Sliding Security Door Lock – Keyed is a reliable replacement solution for sliding security and screen doors originally fitted with Austral® TD7 and Gainsborough® style locks.

Designed for everyday residential use, this lock features a self-latching bolt that automatically engages when the door is closed. The supplied 4-pin cylinder allows the lock to be deadlocked or unlocked from either side using a key, while the internal snib provides convenient locking from inside. The key overrides the snib for added safety.

An anti-lift pin integrated into the striker plate helps prevent the door from being lifted out of its track. The lock is universal and reversible, making it suitable for left- or right-hand door configurations. Upgradeable to a triple lock . Finished in black for durability and corrosion resistance.

Features:
• Supplied with 4-pin cylinder and 3 keys
• Replaces most Austral® TD7 and Gainsborough® sliding door locks
• Self-latching bolt engages automatically on close
• Deadlockable from either side with a key
• Internal snib locking with key override
• Anti-lift striker plate for added security
• Universal / reversible – left or right hand
• Durable black finish

Suitable for:
• Sliding security doors
• Sliding screen doors
• Fly doors
• Residential security doors

Pack Contents:
• Lock body × 1
• Handle & lever assemblies × 2
• 4-pin cylinder × 1
• Keys × 3
• Striker plate with anti-lift pin × 1
• Fixing screws and striker screws
• Fitting instructions

Key Dimensions (reference):
• Overall faceplate height: 160 mm
• Backset: 45 mm
• Faceplate width: 15 mm
• Lock body thickness: 12.5 mm
• Striker plate height: 84.5 mm

Refer to images for full dimensional details.
